Description Features Control: On-Board digital with diagnostics Air supply orientation: Horizontal Filter: 14" x 18" x 2" MERV 11 Refrigerant: R410A Coil type: Copper tube, Aluminum fin with i-coat Drain connection: 3/4" FNPT P-Trap required: No Leveling feet: included Hanging brackets: included Warranty: 5 years on all parts including refrigeration system Included Items Control: Model A76 Drain fittings: 3/4" MNPT x 3/4" BARB Drain tubing (length, ID): 10' - 3/4" ID Thermostat wire: 30' 20 gauge 3-wire Specifications Capacity(1) PPD at 80°/60%RH: 210 Energy factor(1): 3.0L/kW-h - 6,3 pints/kWh Voltage, phase, frequency: 208/240VAC, 1 phase, 60Hz BTU/h(2): 2,036 Current draw (amps)(1): 7.15 Power (Watts)(1): 1,487 Power cord type and length: SJT, 6-15P, 10ft Hardwire: Field configurable Breaker size: 15 amp CFM: 525 Operating range temp/RH: 60/50 to 85/80 Unit dimensions: 19 1/2" W x 18 3/4" H x 30 1/8" L Unit weight: 118 lbs (1)Rated capacity and energy factor test done and current draw measured in accordance with AHAM DH-1 2008 at 80°F/60% RH inlet air at 0.0 ESP. (2)Total cooling load.
