Description Features Control (3): Front mount only Air discharge orientation: End of cabinet only Duct collars: 8" Backdraft damper: No Filter: 1/2" MERV 8 washable Refrigerant: R410A Coil type: Aluminum Power cord length: 8' Hardwire option: No Discharge air temperature rise: 10°F-30°F Drain connection (4): 3/4" MNPT Threaded Specifications Capacity (1): 70 ppd Energy Factor (1): 2.1 L/kW-h Airflow @ varying E.S.P. (external static pressure - dry coil): 0.0" w.c.-200 CFM, 0.2" w.c.-170 CFM, 0.4" w.c.-140 CFM Current draw (1): 5.8 Amps Noise: 53 dBA ducted - 58 dBA unducted Unit dimensions (cabinet only) (2): 12.5" L - 12.5" H - 25" W Unit weight: 56 lbs Inlet air operating conditions during: -Dehumidification: 50°F-104°F, 40°F dew point min. -Ventilation: 40°F-140°F, 0%-99%RH (non-condensing) (1) Rated capacity and energy factor test done and current draw measured in accordance with AHAM DH-1 2008 at 80°F/60%RH inlet air at 0.0 ESP. (2) Height does not include adjustable feet. The width excludes the filter doors and length excludes the duct collars. (3) Built-in automatic control capable to be set up for dehumidification and ventilation or zoning. (4) Adapters for threaded connection for plastic hose included.
